ENGINE AND GEARBOX

Engine Details

155cc, Liquid-Cooled, 4-Stroke, SOHC, 4-Valve, VVA Engine

Fuel System

Fuel Injection

Cooling

Liquid Cooled

Engine cc (Displacement)

155 cc

Maximum Power

18.4 HP @ 10,000 rpm

Maximum Torque

14.2 Nm @ 7,500 rpm

Number of Cylinders

1

Emission Norms

BS6-Compliant

Ignition

T.C.I (Transistor Controlled Ignition)

Lubrication

Wet Sump

Compression Ratio

11.6 : 1

Bore

58.0 mm

Stroke

58.7 mm

Number of Gears

6

Gearbox Type

Constant Mesh

Clutch

Wet, Multiple-Disc

Final Drive

Chain

Side Stand Engine Cut Off

Yes

MILEAGE AND TOP SPEED

Mileage

Yamaha R15M mileage is 40 kmpl (approximate).

Performance

In terms of performance, the sports bike can accelerate from 0-100 kmph in 10.1 seconds.

Top Speed

Yamaha R15M top speed is 150 kmph (approximate).

BRAKES AND TYRES

Front Brake

282mm Single Disc

Rear Brake

220mm Single Disc

ABS

2-Channel ABS

Traction Control System

YES

Front Tyre

100/80-17 M/C 52P

Rear Tyre

140/70-R17 M/C 66H (Radial)

YES

YES

Alloy Wheels

YES

KEY FEATURES AND COMPETITORS

Braking System

2-Channel ABS (Anti-Lock Braking System)

Key Features

Advanced Fully Digital LCD Meter Console, Assist & Slipper Clutch, Variable Valves Actuation (VVA), Traction Control System, Quick Shifter, Upside Down Front Forks, Super Wide 140mm Radial Rear Tyre, Side Stand Engine Cut-Off Switch, Y-connect App - Call Alert, SMS & Email, Phone Battery Status, Fuel Consumption Tracker, Maintenance Recommendations, Last Parking Location, Malfunction Notification, Revs Dashboard, Ranking, Dual Horn, Aluminium Swingarm, Class D Bi-Functional LED Head Light, LED Position Lights, Street and Track Riding Modes.

Ride Modes

Track Mode and Street Mode

Similar Bikes

Suzuki Gixxer SF, KTM RC 125, Yamaha MT-15, Bajaj Pulsar RS200

SUSPENSION AND CHASSIS

Front Suspension

37mm Telescopic Upside Down Fork (USD Forks)

Rear Suspension

Linked-Type Monocross Suspension

Frame (Chassis)

Deltabox

Swingarm

Aluminium Swingarm

DIMENSIONS AND WEIGHT

Overall Length

1990 mm

Overall Width

725 mm

Overall Height

1135 mm

Ground Clearance

170 mm

Seat Height

815 mm

Wheelbase

1325 mm

Kerb Weight

142 kg

Fuel Tank Capacity

11 litres

INSTRUMENT CONSOLE FEATURES

Speedometer

Digital

Tachometer

Digital

Trip Meter

Digital

Odometer

Digital

Clock

Digital, Auto Adjust with Smartphone Connectivity

ABS Light

YES

Fuel Gauge

Digital

Gear Indicator

YES

Low Oil Indicator

YES

Low Battery Indicator

YES

Rev-limiter Indicator

YES

Mobile Phone Connectivity Via Bluetooth

Y-Connect (Smartphone Bluetooth Connectivity)

BATTERY AND LIGHTING

Pass Light

YES

Battery Type

Maintenance Free

Capacity

4.0Ah

Voltage

12V

Head Light

Bi-functional LED (Class D)

Tail Light

LED

Turn Signal Light (Front)

12V, 10W×2

Turn Signal Light (Rear)

12V, 10W×2

Position Lamp

LED

Automatic Headlamp On (AHO)

YES

COMFORT FEATURES

Electric Start

YES

Pillion Footrest

YES

Step-up Seat/Split Seat

YES

Engine Kill Switch

YES

Riding Modes

Track Mode and Street Mode
